PC Steel Raw Material Spring Steel Wire Prestressed Concrete Strand With Reducing Distortion

PC Steel Raw Material Spring Steel Wire Prestressed Concrete Strand With Reducing Distortion

  • High Light

    seven strand wire

    ,

    7 wire PC Strand

  • Material
    High Carbon Wire Rod 82B
  • Tensile Strength
    Min.1860MPA
  • Production Standard
    ASTM,GB/T,JISG Etc.
  • Size
    9.53mm,12.7mm,15.24mm
  • Construction
    1*7
  • Packing
    2.5-3.2tons/coil On 2 Pallets
  • Loading Capacity
    25-26.5tons/20"
  • Place of Origin
    ANHUI,CHINA
  • Brand Name
    Litong Global
  • Certification
    ISO9001
  • Model Number
    LT-2016090102
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    2.5-3.2tons/coil on 2 pallets
  • Supply Ability
    1000tons/day

PC Steel Raw Material Spring Steel Wire Prestressed Concrete Strand With Reducing Distortion

Steel strand twisted by round steel wire used for prestressed concrete structure, rock or earth enchorage etc.

Features:

(1) Construction: 1 x 7

(2) Diameter: 9.53mm, 12.7mm, 15.24mm

Note:
According to different uses. We can supply PC stranded wire wtih the other tensile strength and diameter through negotiation by both parties.

Packing: Coils.


Specifications

Compositon Nominal dia.
(mm)
Area of section
(mm)
Tolerance
(mm)
Tensile strength
grade (MPa)
Breaking force
(KN) no less than
Yielding load

(KN) no less than
Elongation
(lo>=500mm)%
no less than
Relxation value 1000h% no more than
1*7 9.50 54.8 +0.30
-0.15
1860 102 86.6 3.5 2.5
1*7 12.70 98.7 +0.40
-0.20
1860 184 156 3.5 2.5
1*7 15.20 139 +0.40
-0.20
1860 259 220 3.5 2.5
