hot-dipped Galvanized steel wire strand used on guy wire,tranmission line,overhead lines,communications etc as per ASTM A 475,ASTM B 498,BS183,IEC888 etc
We are an ISO 9001 certificated manufacturer of Galvanized(Zinc-Coated)steel wire & Strand, for Power & Communication cables materials, Static(Overhead Earth) wire, Guy(Stay) wire , Steel structural, Agricultural & fence usage.
We can provide below quality goods:
1)Messenger wire
Size: 7×1.4mm to 7×4.19mm ( 3/16inch, 1/4inch, 5/16inch, 3/8inch, 1/2inch)
Standard: ASTM A 475-98
2)Galvanized steel core wires for Aluminum conductor ( ACSR)
Size: 1.44mm to 4.77mm , 7×1.44mm to 7×4.25mm , 19×1.6mm to 19×4.0mm
Standard: ASTM B 498, BS 4546, IEC 60888, EN 50189
3)Galvanized steel wires strand for poles or communication towers (Stay wire/guy wire of Poles or towers; Ground wire or Earth wire )
Size: 7×1.4mm to 7×4.25mm , 19×1.6mm to 19×3.8mm,3×2.64mm to 3×4.00mm
Standard: ASTM A 363, ASTM A 475, BS 183...
4)Galvanized steel wires or strand for Cattle cable/Greenhouse/Fence
Size: Plian wire 2.5, 2.8, 3.15, 4.0mm, 8.25mm with 7 wires, 10mm with 19 wires,7×1.57mm(3/16inch)
With high quality, our goods have being expored to USA, Bahrain, Mexico, Chile, Peru, France, Vietnam, Phillippines over 25 countries.
Type | 1x7 | Type |
| 1x19 | |||||||||
Nominal Diameter | Nominal Area | Min.Breaking Strength(MPA) | Nominal Diameter |
| Nominal Area | Min.Breaking Strength(MPA) | |||||||
Single Wire Dia. | Strand Wire Dia. | 1270 | 1370 | 1470 | 1570 | Single Wire Dia. | Strand Wire Dia. | 1270 | 1370 | 1470 | 1570 | ||
mm | Mm2 | Min. Breaking Load(KN) | mm | Mm2 | Min. Breaking Load(KN) | ||||||||
1.6 | 4.8 | 14.07 | 16.40 | 17.70 | 19.00 | 20.80 | 1.6 | 8.0 | 38.20 | 43.6 | 47.10 | 50.50 | 53.90 |
1.7 | 5.1 | 15.89 | 18.00 | 20.00 | 21.40 | 22.90 | 1.8 | 9.0 | 48.35 | 55.20 | 59.60 | 63.90 | 68.30 |
1.8 | 5.4 | 17.81 | 20.80 | 22.40 | 24.00 | 25.70 | 2.0 | 10.0 | 59.69 | 68.20 | 73.60 | 78.90 | 84.30 |
2.0 | 6.0 | 21.99 | 25.60 | 27.70 | 29.70 | 31.70 | 2.2 | 11.0 | 72.22 | 82.50 | 89.00 | 95.50 | 102.00 |
2.2 | 6.6 | 26.61 | 31.00 | 33.50 | 35.90 | 38.40 | 2.4 | 12.0 | 85.95 | 98.20 | 105.00 | 113.00 | 121.00 |
2.4 | 7.2 | 31.67 | 37.00 | 39.90 | 42.80 | 45.70 | 2.5 | 12.5 | 93.27 | 106 | 114.00 | 123.00 | 131.00 |
2.6 | 7.8 | 37.16 | 43.40 | 46.80 | 50.20 | 53.60 | 2.6 | 13.0 | 100.88 | 115 | 124.00 | 133.00 | 142.00 |
2.8 | 8.4 | 43.10 | 50.30 | 54.30 | 58.20 | 62.20 | 2.8 | 14 | 116.99 | 133 | 144.00 | 154.00 | 165.00 |
3.0 | 9.0 | 49.48 | 57.80 | 62.30 | 66.90 | 71.40 | 3.0 | 15 | 134.30 | 153 | 165.00 | 177.00 | 189.00 |
