Industrial Galvanized Stay Wire Strand , Galvanized Steel Core Wire Strand For Telegraph And Telephone Poles

Industrial Galvanized Stay Wire Strand , Galvanized Steel Core Wire Strand For Telegraph And Telephone Poles

  • Industrial Galvanized Stay Wire Strand , Galvanized Steel Core Wire Strand For Telegraph And Telephone Poles
  • Industrial Galvanized Stay Wire Strand , Galvanized Steel Core Wire Strand For Telegraph And Telephone Poles
Industrial Galvanized Stay Wire Strand , Galvanized Steel Core Wire Strand For Telegraph And Telephone Poles
Product Details:
Place of Origin: Anhui,China
Brand Name: Litong Global
Certification: ISO9001 and other 3rd party Inspection report
Model Number: LT-160704
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: In Coil or on Drum
Delivery Time: 10 days after confirmed order
Payment Terms: TT/LC
Supply Ability: 400tons/day
Contact Now
Detailed Product Description
Steel Grade: Middle And High Carbon Wire Rod Wire Gauge: 1.0-4.8mm
Type: Galvanized Alloy Or Not: Non-alloy
Special Use: Cold Heading Steel Application: Guy Wire,stay Wire,ACSR Conductor,rope Etc.
Standard: AISI|ASTM|BS|DIN|GB|JIS
High Light:

acsr conductor

,

acsr panther conductor

  • Stay Wire



    It is hot dip galvanized stay strand for telegraph & telephone poles, transmission lines poles, signal poles, railway track signals.

    Material: The wire is cold drawn from steel and coated with zinc, the finish strand and the individual wires having uniform quality and have the properties and product characteristics as specified in technical specification.

    Construction: 7 Strand (6+1)

    Earth_Wire

    Specification: IS:2141, BS:183
    Size: 7/1.60 to 7.40mm



    COIL SPECIFICATIONS:

    Grade

    Tensile Grade

    Min. Tensile Strength

    (N/mm2)

    1

    1770

    1770

    2

    1570

    1570

    3

    1100

    1100

    4

    700

    700

    5

    450

    450



    MARKING: As specified by the purchaser which is legibily stamped/written on a suitable tag security attached when galvanized stay strands are supplied in coil. In case of galvanized stay strands are supplied in reels, the informations are written on both side of the reels and suitably tag giving the same information be attached on the side of the reel.
    PACKING:

    The galvanized steel stay strand protected with paper/polythene/HDPE and outside wooden laggin on drum/reel.

  •
