Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape

Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape

  • Highlight

    acsr conductor

    ,

    overhead line conductor

  • Model NO
    ASTM B232
  • Type
    Bare
  • Conductor Type
    Stranded
  • Application
    Overhead
  • Conductor Material
    ACSR
  • Sheath Material
    Bare
  • Insulation Material
    Bare
  • Material Shape
    Round Wire
  • Certification
    ISO,CCC
  • Standard
    ASTM B232 BS215
  • Voltage
    High Voltage
  • Product Name
    ACSR Conductor
  • HS Code
    7614100000
  • Place of Origin
    ANHUI,CHINA
  • Brand Name
    Litong Global
  • Certification
    ISO9001&CCC
  • Model Number
    LT-201608311
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable

Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape

Product Description
Aluminum Conductor Steel Reinforced Bare Aluminum Cable ACSR Conductor

1.Application
ACSR Conductor have been widely used in power transmission lines with various voltage levels, and also used in power lines across great Rivers, plain,highland etc. The cables have excellent advantages of high strength, large current carrying capacity and good catenary property as well as wear-resistance, anti-crush and corrosion-proof with simple structure, convenient and low cost installation and maintenance, large transmission capacity.

2.Standard
ASMTB232 Standard specification for concentric-lay-stranded aluminum conductors, coated-steel reinforced ACSR Conductor


3.Specification
Aluminum 1350-H19 wires, concentrically stranded around steel core wire for ACSR conductor is available with class A, B, or C galvanizing; "aluminized" aluminum coated(AZ); or aluminum - clad - (AW). Additional corrosion protection is available through the application of grease to the core or infusion of the complete cable.
ASTM B232 Standard about ACSR Conductor
Code Name Size No./Dia.of Stranding Wires Approx. Overall Dia. Approx. Weight
AWG or MCM Aluminum Steel
No./mm No./mm mm kg/km
Turkey 6 6/1.68 1/1.68 5.04 54
Swan 4 6/2.12 1/2.12 6.36 85
Swanate 4 7/1.96 1/2.61 6.53 100
Sparrow 2 6/2.67 1/2.67 8.01 136
Sparate 2 7/2.47 1/3.30 8.24 159
Robin 1 6/3.00 1/3.00 9 171
Raven 1/0 6/3.37 1/3.37 10.11 216
Quail 2/0 6/3.78 1/3.78 11.34 273
Pigeon 3/0 6/4.25 1/4.25 12.75 343
Penguin 4/0 6/4.77 1/4.77 14.31 433
Waxwing 266.8 18/3.09 1/3.09 15.45 431
Partridge 266.8 26/2.57 7/2.00 16.28 546
Ostrich 300 26/2.73 7/2.12 17.28 614
Merlin 336.4 18/3.47 1/3.47 17.5 544
Linnet 336.4 26/2.89 7/2.25 18.31 689
Oriole 336.4 30/2.69 7/2.69 18.83 784
Chickadee 397.5 18/3.77 1/3.77 18.85 642
Brant 397.5 24/3.27 7/2.18 19.61 762
Ibis 397.5 26/3.14 7/2.44 19.88 814
Lark 397.5 30/2.92 7/2.92 20.44 927
Pelican 477 18/4.14 1/4.14 20.7 771
Flicker 477 24/3.58 7/2.39 21.49 915
Hawk 477 26/3.44 7/2.67 21.79 978
Hen 477 30/3.20 7/3.20 22.4 1112
Osprey 556.5 18/4.47 1/4.47 22.35 899
Parakeet 556.5 24/3.87 7/2.58 23.22 1067
Dove 556.5 26/3.72 7/2.89 23.55 1140
Eagle 556.5 30/3.46 7/3.46 24.21 1298
Peacock 605 24/4.03 7/2.69 24.2 1160
