Identity of galvanized steel wire Strand | ||||||
Nominal Dia.Strand | Number of Wires | Diameter of Wires | Mass Approximately | Minimum Breaking strength,1bf(KN) | ||
General | High | Extra High | ||||
(mm) | LB/1000FT(KG/M) | |||||
1/8(3.18) | 7 | 0.041(1.04) | 32(48) | 540 | 1330 | 1830 |
5/32 | 7 | 0.052(1.32) | 51(76) | 870 | 2140 | 2940 |
3/16(4.76) | 7 | 0.062(1.57) | 73(109) | 1150 | 2850 | 3990 |
7/32(5.56) | 3 | 0.104(2.64) | 88(131) | 1400 | 3500 | 490 |
7/32(5.56) | 7 | 0.072(1.83) | 98(146) | 1540 | 3850 | 5400 |
1/4(6.35) | 3 | 0.120(3.05) | 117(174) | 1860 | 4730 | 6740 |
1/4(6.35) | 7 | 0.080(2.03) | 121(180) | 1900 | 4750 | 6650 |
9/32(7.14) | 3 | 0.130(3.30) | 137(204) | 2080 | 5260 | 7500 |
9/32(7.14) | 7 | 0.093(2.36) | 164(244) | 2570 | 6400 | 8950 |
5/16(7.94) | 3 | 0.145(3.68) | 171(255) | 2490 | 6350 | 9100 |
5/16(7.94) | 7 | 0.104(2.64) | 205(305) | 3200 | 8000 | 11200 |
3/8(9.52) | 7 | 0.165(4.19) | 220(328) | 3330 | 8360 | 11800 |
3/8(9.52) | 3 | 0.120(3.05) | 273(407) | 4520 | 10800 | 15400 |
7/16(11.11) | 7 | 0.145(3.68) | 399(595) | 5700 | 14500 | 20800 |
1/2(12.70) | 7 | 0.165(4.19) | 517(770) | 7400 | 18800 | 26900 |
1/2(12.70) | 19 | 0.100(3.54) | 504(751) | 7620 | 19100 | 26700 |
9/16(14.29) | 7 | 0.188(4.78) | 671(1000) | 9600 | 24500 | 35000 |
9/16(14.29) | 19 | 0.113(2.87) | 637(949) | 6940 | 24100 | 33700 |
5/8(15.88) | 7 | 0.207(5.26) | 813(1211) | 11600 | 19600 | 42400 |
5/8(15.88) | 19 | 0.125(3.18) | 796(1186) | 11000 | 28100 | 40200 |
3/4(19.05) | 19 | 0.150(3.81) | 1155(1721) | 16000 | 40800 | 58300 |
7/8(22.22) | 19 | 0.177(4.5) | 1581(2356) | 21900 | 55800 | 79700 |
1(25.40) | 19 | 0.200(5.08) | 2073(3089) | 28700 | 73200 | 104500 |
1(25.40) | 37 | 0.143(3.63) | 2057(3065) | 28300 | 71900 | 102700 |
9/8(28.58) | 37 | 0.161(4.09) | 2691(4010) | 36000 | 91600 | 130800 |
5/4(31.75) | 37 | 0.179(4.55) | 3248(4840) | 44600 | 113600 | 162200 |
