Anhui Litong Rare-earth Steel Cable Co.,Ltd is a company to produce and export different types of Galvanized steel wire for electricity and communication.
Features
Applications
Our Galvanized Steel Wire /strand is used for guy wire ,telegraph pole, farming purposes, and optical cables, guy wire, ground wire(stay wire),Steel Core for ACSR Conductor, barrier cables, messenger wires.
|
Grade |
Dia. (mm) |
Tensile Strength Not less (Mpa) |
Stress at elongation of 1% Not less (Mpa) |
Elongation L0=250mm Not less |
Torsion Not less Times/360° |
Mandrel Dia |
| ≥1.24-2.25 | 1340 | 1170 | 3.0 | 16 | 1 | |
|
Normal |
≥2.25-2.75 | 1310 | 1140 | 3.0 | 16 | 1 |
| ≥2.75-3.00 | 1310 | 1140 | 3.5 | 16 | 1 | |
| ≥3.00-3.50 | 1290 | 1100 | 3.5 | 14 | 1 | |
| ≥3.5-4.25 | 1290 | 1100 | 4.0 | 12 | 1 | |
| ≥4.25-4.75 | 1290 | 1100 | 4.0 | 12 | 1 | |
| ≥4.75-5.5 | 1290 | 1100 | 4.0 | 12 | 1 | |
|
High |
≥1.24-2.25 | 1450 | 1310 | 2.5 | 16 | 1 |
| ≥2.25-2.75 | 1410 | 1280 | 2.5 | 16 | 1 | |
| ≥2.75-3.00 | 1410 | 1280 | 3.0 | 16 | 1 | |
| ≥3.00-3.50 | 1410 | 1280 | 3.0 | 14 | 1 | |
| ≥3.5-4.25 | 1380 | 1240 | 3.0 | 12 | 1 | |
| ≥4.25-4.75 | 1380 | 1170 | 3.0 | 12 | 1 | |
| ≥4.75-5.5 | 1380 | 1170 | 3.0 | 12 | 1 | |
|
Extra- High |
≥1.24-2.25 | 1620 | 1450 | 2.0 | 14 | 1 |
| ≥2.25-2.75 | 1590 | 1410 | 2.0 | 14 | 1 | |
| ≥2.75-3.00 | 1590 | 1410 | 2.5 | 12 | 1 | |
| ≥3.00-3.50 | 1550 | 1380 | 2.5 | 12 | 1 | |
| ≥3.5-4.25 | 1520 | 1340 | 2.5 | 10 | 1 | |
| ≥4.25-4.75 | 1520 | 1340 | 2.5 | 10 | 1 | |
| ≥4.75-5.5 | 1520 | 1270 | 2.5 | 10 | 1 |
