Multifunctional Galvanized Steel Wire Strand , 3 /8 "Galvanized Aircraft Cable For Messenger

Multifunctional Galvanized Steel Wire Strand , 3 /8 "Galvanized Aircraft Cable For Messenger

Multifunctional Galvanized Steel Wire Strand , 3 /8 "Galvanized Aircraft Cable For Messenger
Multifunctional Galvanized Steel Wire Strand , 3 /8 "Galvanized Aircraft Cable For Messenger

Product Details:

Place of Origin: Anhui,China
Brand Name: Litong Global
Certification: ISO9001 and other 3rd party Inspection report
Model Number: LT-160824

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: In Coil or on Drum or Z2 Packing
Delivery Time: 10-15days after confirmed order
Payment Terms: TT/LC
Supply Ability: 400tons/day
Contact Now
Detailed Product Description
Steel Grade: Low&Middle And High Carbon Wire Rod Wire Gauge: 1.0-4.8mm
Type: Galvanized Alloy Or Not: Non-alloy
Special Use: Cold Heading Steel Application: ACSR, Ground Wire, Suspension Bracket, Communication Cable, Stay Wire.
Standard: AISI|ASTM|BS|DIN|GB|JIS
High Light:

galvanized cable wire

,

galvanized steel strand

Galvanized Steel Wire/Strand
  Our range of Galvanized Steel Wire/Strand(called”steel wire) has been designed for superior efficiency and performance.Steel Wire manufacturing has been Litong Cable’s initial products since established factory in 2000.It has today evolved into the country’s main larger player with a domestic share of over 15% ,esp.in China State Grid and an installed capacoty of over10,000MT.Product Range
Our Galvanized Steel Wire &Strand include:
.Main Single Wire Size:1.0mm-4.8mm
.Structure of Strand:1*2,1*4 ,1*7 &1*19
.Main Production Standard:ASTM B 498,IEC888,GB/T3428, YB(T)13-83,ASTM B 80,ASTM B 500 ,ASTM A 475,BS183,YB/T5004,GB/T-20492,ASTM B 803,ASTM A 640 etc.
Application:ACSR Conductor,Telecommission,Guy Wire,Messenger,Overhead transmission,stay wire,etc.
Approvals,Certifications and Testing
.ISO9001-2008 Certified
.SGS-Tested
.NMCI-Tested
.CANS-Certified
 Technical Parameters
Galvanized Steel Wire as per ASTM B 498

Wire Diamater(mm)

Diamater Tolerance(mm)

Weight of Zinc-coating(g/m2)

Stress at 1% Extension,Min(Mpa)

Tensile Strength
Min.(Mpa)

Elongation in 250mm,Min(%)

1.57-1.90

+0.04,-0.03

210

1310

1450

3.0

Over 1.9-2.3

+0.04,-0.03

220

1310

1450

3.0

Over 2.3-2.7

+0.05,-0.05

230

1280

1410

3.5

Over 2.7-3.1

+0.05,-0.05

240

1280

1410

3.5

Over3.1-3.5

+0.08,-0.05

260

1240

1410

4.0

Over 3.5-3.9

+0.08,-0.05

270

1240

1410

4.0

Over 3.9-4.5

+0.1,-0.08

275

1170

1380

4.0

Over 4.5-4.8

+0.1,-0.08

300

1170

1380

4.0

Galvanized Steel Wire Strand as per ASTM A 475

Norminal Diamater of Strand

No. of  Wires

Diamater of Wire

Tolerance of Wire

Weight

Zinc-coating

Breaking Loading

mm

-

mm

mm

Kg/Km

g/m2

KN

3.18

7

1.04

±0.05

48

122

8.14

3.97

7

1.32

±0.05

76

122

13.078

4.76

7

1.57

±0.08

109

153

17.748

5.56

7

1.83

±0.08

146

153

24.02

6.35

7

2.03

±0.08

180

183

29.581

7.14

7

2.36

±0.10

244

214

39.812

7.94

7

2.64

±0.10

305

244

49.82

9.52

7

3.05

±0.10

407

259

68.503

11.11

7

3.68

±0.13

595

275

92.523

12.7

7

4.19

±0.13

770

275

119.657
