High Carbon Wire Rod Galvanized Steel Wire Strand For Vibration Damper

High Carbon Wire Rod Galvanized Steel Wire Strand For Vibration Damper

  • High Carbon Wire Rod Galvanized Steel Wire Strand For Vibration Damper
  • High Carbon Wire Rod Galvanized Steel Wire Strand For Vibration Damper
  • High Carbon Wire Rod Galvanized Steel Wire Strand For Vibration Damper
  • High Carbon Wire Rod Galvanized Steel Wire Strand For Vibration Damper
High Carbon Wire Rod Galvanized Steel Wire Strand For Vibration Damper
Product Details:
Place of Origin: Anhui,China
Brand Name: Litong Global
Certification: ISO9001-2008
Model Number: LT-160321
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: In Coil or on Packing
Delivery Time: 10 days after confirmed order or as per order quantity
Payment Terms: TT/LC
Supply Ability: 400tons/day
Contact Now
Detailed Product Description
Steel Grade: High Carbon Wire Rod Wire Gauge: 1.0-4.5mm
Type: Galvanized Alloy Or Not: Non-alloy
Special Use: Cold Heading Steel Application: ACSR Conductor,Guy Wire,Stay Wire
Standard: AISI|ASTM|BS|DIN|GB|JIS
High Light:

optical ground wire

,

optical fiber ground wire

Galvanized Steel Core Wire for ACSR Conductor as per ASTM B 498



Wire Diamater(mm)

Diamater Tolerance(mm)

Weight of Zinc-coating(g/m2)

Stress at 1% Extension,Min(Mpa)

Tensile Strength
Min.(Mpa)

Elongation in 250mm,Min(%)

1.57-1.90

+0.04,-0.03

210

1310

1450

3.0

Over 1.9-2.3

+0.04,-0.03

220

1310

1450

3.0

Over 2.3-2.7

+0.05,-0.05

230

1280

1410

3.5

Over 2.7-3.1

+0.05,-0.05

240

1280

1410

3.5

Over3.1-3.5

+0.08,-0.05

260

1240

1410

4.0

Over 3.5-3.9

+0.08,-0.05

270

1240

1410

4.0

Over 3.9-4.5

+0.1,-0.08

275

1170

1380

4.0

Over 4.5-4.8

+0.1,-0.08

300

1170

1380

4.0


Galvanized Steel Wire Strand for ACSR Conductor as per ASTM A 475


Norminal Diamater of Strand

No. of  Wires

Diamater of Wire

Tolerance of Wire

Weight

Zinc-coating

Breaking Loading

mm

-

mm

mm

Kg/Km

g/m2

KN

3.18

7

1.04

±0.05

48

122

8.14

3.97

7

1.32

±0.05

76

122

13.078

4.76

7

1.57

±0.08

109

153

17.748

5.56

7

1.83

±0.08

146

153

24.02

6.35

7

2.03

±0.08

180

183

29.581

7.14

7

2.36

±0.10

244

214

39.812

7.94

7

2.64

±0.10

305

244

49.82

9.52

7

3.05

±0.10

407

259

68.503

11.11

7

3.68

±0.13

595

275

92.523

12.7

7

4.19

±0.13

770

275

119.657
