ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight

ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight

  • ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight
  • ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight
  • ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight
  • ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight
ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight
Product Details:
Place of Origin: ANHUI,CHINA
Brand Name: LITONG GLOBAL
Certification: ISO9001-2008
Model Number: LT-161227(1)
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Export Packing, Standard Export Packing
Supply Ability: 800tons/day
Contact Now
Detailed Product Description
Model NO.: 9.3, 9.53, 11.1, 12.5, 12.7, 15.2, 15.7, 21.8mm Relaxation At 1000h Not More Than: 2.5%
Ensil Strength: 1720~1960mpa Coil Size: ID 0.70-0.72m, Od 1.0-1.5m, Width 0.76m
Elongation At Max Load Not Less Than: 3.5% Alloy Or Not: Non-Alloy
Coil Weight: 2.0~3.5 Tons Transport Package: Export Packing, Standard Export Packing
Specification: GB, ASTM, DIN, BS HS Code: 73121000
High Light:

pc strand wire

,

7 wire PC Strand

Product Description

1*7 Wires Low Relaxation PC Strand
Description:
High tensile low relaxation steel strand for prestressed concrete
Specification:
Raw Material: High carbon steel wire rod SWRH 82B
Sizes: 9.3, 9.53, 10.8, 11.1, 12.5, 12.7, 12.9, 15.2, 15.7, 17.8, 18.0, 18.9, 21.6, 21.8mm
Standards: ASTM A416-2006, ASTM A910-2005, ABNT NBR 7483:2008, AS 1311(Australia), AS/NZS 4672.1, BS5896-1980, EN10138-3, GB/T5224-2003, IS6006-1983, JISG3536, KSD7002, UNE36094-97 (Spain), NEN3868

7-Wire Uncoated Steel Strand for Prestressed Concrete as per ASTM A 416

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation

MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.53





+0.66,-0.15

54.84 432 102.3 92.1





≥3.5





≤2.5

11.11 74.19 582 137.9 124.1
12.70 98.7 775 183.7 165.3
15.24 140.0 1102 260.7 234.6
17.80 190.0 1492 353.0 318.0
2000 12.70 +0.66,-0.15 98.7 775 197.4 177.7 ≥3.5 ≤2.5
15.24 140.0 1102 280.0 252.0



7-Wire Uncoated Steel Strand for Prestressed Concrete as per GB/T5224

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation

MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.50 +0.30,-0.15 54.8 432 102 86.6





≥3.5





≤2.5

  11.10 74.2 580 138 117
  12.70





+0.40,-0.20

98.7 775 184 156
  15.20 140 1101 259 220
  15.70 150 1178 279 251
  17.80 191 1500 353 318
1960 12.70 +0.40,-0.20 98.7 775 193 174 ≥3.5 ≤2.5
  15.20 140 1101 274 247



Usages:
Pre-stressing steels apply to post-tensioned and pre-tensioned concrete structure in the follow civil engineering, building construction and infrastructure projects: bridges; railway sleeper, subway track board; airport; industrial buildings, commercial buildings, residential housing foundations; PC poles, piles, beams, girders, slabs, double-T board, hollow floor board, floor, parking decks, PHC, PPCP; electric power, nuclear power station; ports, dams, water project, sewage treatment, swimming pool; rock-coil anchoring, side slope stabilization, coil mine; storage tank for national gas, oil, grain; stadiums, TV tower etc.

ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight 0

Production Process:

ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight 1

Trade Terms:
Min Order Qty: 1FCL / 25T
Delivery Time: 10-15 days
Price Terms: FOB CFR CIF
Payment Terms: TT / LC

Packing&Loading

ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight 2





Contact us:

ASTM A416 BS 5896 7 Wire Strand Pc Steel With 2.0-3.5 Tons Coil Weight 3
