Galvanized Steel Core Wire for ACSR Conductor

Galvanized Steel Core Wire for ACSR Conductor

  • High Light

    galvanised steel wire

    ,

    zinc coated wire

  • Steel Grade
    High Carbon Wire Rod
  • Wire Gauge
    1.0-4.8mm
  • Type
    Galvanized
  • Alloy Or Not
    Non-alloy
  • Special Use
    Free Cutting Steel
  • Application
    Bare ACSR Conductor
  • Standard
    AISI, ASTM, BS, DIN, GB, JIS
  • Place of Origin
    Anhui ,China
  • Brand Name
    Litong Global
  • Certification
    ISO9001GS&Other 3rd party Inspection report
  • Model Number
    LT-150924
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    in coil or on drum
  • Delivery Time
    10 days after confirmed order or as per order quantity
  • Payment Terms
    TT/LC
  • Supply Ability
    400tons/Day

Galvanized Steel Core Wire for ACSR Conductor

Galvanized Steel Core Wire for ACSR Conductor as per ASTM B 498



Wire Diamater(mm)

Diamater Tolerance(mm)

Weight of Zinc-coating(g/m2)

Stress at 1% Extension,Min(Mpa)

Tensile Strength

Min.(Mpa)

Elongation in 250mm,Min(%)

1.57-1.90

+0.04,-0.03

210

1310

1450

3.0

Over 1.9-2.3

+0.04,-0.03

220

1310

1450

3.0

Over 2.3-2.7

+0.05,-0.05

230

1280

1410

3.5

Over 2.7-3.1

+0.05,-0.05

240

1280

1410

3.5

Over3.1-3.5

+0.08,-0.05

260

1240

1410

4.0

Over 3.5-3.9

+0.08,-0.05

270

1240

1410

4.0

Over 3.9-4.5

+0.1,-0.08

275

1170

1380

4.0

Over 4.5-4.8

+0.1,-0.08

300

1170

1380

4.0

Test Equipments of our Company:Anhui Litong Rare-earth Steel Cable Co.,Ltd
