ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa

ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa

  • ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
  • ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
  • ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
Product Details:
Place of Origin: Anhui,China
Brand Name: Litong Global
Certification: ISO9001-2008
Model Number: LT-PC0426
Payment & Shipping Terms:
Minimum Order Quantity: 25tons
Price: discuss
Packaging Details: standard export packing in coil on 2 pallets
Supply Ability: 800tons/day
Contact Now
Detailed Product Description
Material:: 82B Wire Rod Size:: 0.5",0.6"
Structure:: 1x7 And 1x19 Standard:: ASTM A 416
Grade:: 1860MPA Packing:: 2.5-3.2tons/coil
High Light:

pc strand wire

,

seven strand wire

ASTM A 416 12.7mm (0.5")PC Strand for Railway Sleeper 1860Mpa

Prestressed Concrete Steel Strand(PC Strand)

PC Strand is our most popular products in domestic and abroad market now.All of production lines for PC Strand,we introduce from MARIO FRIGERIO in Italy,Which is the first-class in the line in the World.upto 95% domestic market in Anhui Province,covered by us.We win most major projects through tenders from developed high-speed rail in China ,relying on our excellent quality.Litong’s PC Strand Annual output reached 100,000MT.

ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa 0

Product Range

Our PC Strand include:

.Size:9.53mm,12.7mm,15.24mm,17.8mm(9.5mm,12.7mm,15.2mm,15.7mm)

.Structure of Stand:1*7

.Main Production Standard:ASTM A 416,GB/T5224,BS5896,JIS G3536 etc.

.Application:High-speed rail.,Road bridge,buildings,foundations,stadiums,airport hangers, pre-cast segments, crane beams, anchorages and multi-storey industrial buildings etc.

ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa 1

Approvals,Certifications and Testing

.ISO9001-2008

. CANS-Certified

. China National Construction Steel Quality Supervision and Test Center Railway Construction Inspection Station

.SGS

.Vietnam Government ITST Test Report



ASTM A 416 12.7mm ( 0.5" ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa 2



Techical Parameters

7-Wire Uncoated Steel Strand for Prestressed Concrete as per ASTM A 416

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation

MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.53





+0.66,-0.15

54.84 432 102.3 92.1





≥3.5





≤2.5

11.11 74.19 582 137.9 124.1
12.70 98.7 775 183.7 165.3
15.24 140.0 1102 260.7 234.6
17.80 190.0 1492 353.0 318.0
2000 12.70 +0.66,-0.15 98.7 775 197.4 177.7 ≥3.5 ≤2.5
15.24 140.0 1102 280.0 252.0



























7-Wire Uncoated Steel Strand for Prestressed Concrete as per GB/T5224

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation

MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.50 +0.30,-0.15 54.8 432 102 86.6





≥3.5





≤2.5

  11.10 74.2 580 138 117
  12.70





+0.40,-0.20

98.7 775 184 156
  15.20 140 1101 259 220
  15.70 150 1178 279 251
  17.80 191 1500 353 318
1960 12.70 +0.40,-0.20 98.7 775 193 174 ≥3.5 ≤2.5
  15.20 140 1101 274 247
